Key Benefits
Basic clamp 10pcs - SWL 160kg(SF8:1) for 32-35mm tube, black anodized
Elevate your rigging set-up with the CELL131 -anodized clamp, a robust and user-friendly solution designed to secure equipment to 32–35-mm (1.26–1.38-in) diameter tubes. Crafted from precision-extruded high-tensile aluminium alloy, this clamp combines lightweight portability with impressive durability, making it perfect for exhibitions, stage set-ups and structural displays. Rated with a safe working load (WLL) of 160 kg (353 lbs) for a safety factor of 8:1 in accordance with DGUV V17/BGV C1, and offering even higher capacity with a safety factor of 4:1 in accordance with 2006/42/EC, it delivers trusted performance for professional applications.
Dimensions
- Length (mm)
- 64.0
- Width (mm)
- 30.0
- Height (mm)
- 67.0
- Tube diameter (mm)
- 32-35
- Cell body width (mm)
- 30.0
Others
- Material
- High Tensile Aluminium
- WLL (kg)
- 160.0
- Clamp type
- Basic
- Fixing method
- Regular
- Self-weight (kg)
- 0.1
