Parallel truss coupler 5pcs -SWL 650kg(SF8:1) for 60-63,5mm tube
CELL306|5pcs

Parallel truss coupler 5pcs -SWL 650kg(SF8:1) for 60-63,5mm tube

The CELL306 clamp is a set of two clamps fixed parallel to each other for connecting two tubes. Sold only as 5 pcs.

Get more info or quote

Key Benefits

• Designed to suit 60–63.5-mm (2.36–2.50-in) diameter tubes
• Mounting hole suitable for up to 13-mm (0.51-in) bolts
• Precision-extruded high-tensile aluminium alloy
• Polished surface with micro-percussion marking
• DGUV V17 / BGV C1 rating
• Compatible with M950 / 4GS-91
• Rated with SF 8:1 (kg) DGUV V17 /BGV C1 (WLL1)
• Rated with SF 4:1 (kg) 2006/42/EC (WLL2)
• Supplied with M12 eye bolt and wingnut

Parallel truss coupler 5pcs -SWL 650kg(SF8:1) for 60-63,5mm tube

The CELL306 clamp is a set of two clamps fixed parallel to each other for connecting two tubes. Part of the reliable CELL300 clamp series, it is designed for securely attaching equipment to tubes with a diameter of 60–63.5 mm (2.36–2.50 in), making it ideal for event, exhibition and structural set-ups. Crafted from precision-extruded high-tensile aluminium alloy, this clamp combines lightweight construction with exceptional strength and durability.
With a WLL of 650 kg (1433 lbs) with a safety factor of 8:1 in accordance with DGUV V17/BGV C1 and a higher capacity with a safety factor of 4:1 in accordance with 2006/42/EC, the CELL306 clamp is built to meet rigorous safety standards.

Dimensions

Length (mm)
119.0
Width (mm)
50.0
Height (mm)
222.0
Tube diameter (mm)
60-63,5
Cell body width (mm)
50.0

Others

Material
High Tensile Aluminium
WLL (kg)
650.0
Clamp type
Parallel Coupler
Fixing method
Regular
Self-weight (kg)
1.5
